Smooth model

The smooth jaw workholding clamps are specifically engineered to securely hold your workpiece without leaving any  visible marks or scratches.

Our smooth jaw clamps are among OK-VISE’s oldest designs and remain a popular choice due to their low profile and durability. Made with high-quality materials, the clamp is built to last, saving you money and time. The clamp is easy to install and adjust, allowing you to quickly and efficiently secure your workpiece with precision.

Details

Details

TypePressing force of Jaws (max)Tightening torgue (max)Socket Head Srew DIN 912DownloadsTechnical details
BK2-VT-S 25 kN44 NmM8x20
Technical details — BK2-VT-S

BK2-VT-S

Dimension drawing — BK2-VT-S
A min
27 mm
A optimum
29 mm
A max
31 mm
B
29 mm
C
15 mm
D
21 mm
E
2.5 mm
Socket Head Srew DIN 912
M8x20
Pressing force of Jaws (max)
25 kN
Tightening torgue (max)
44 Nm
Weight
55 g
Hardness of Jaws
48-52 HRC
Dimensions
PDF drawings
STEP (3D)
STEP (3D)
 DK2-VT-S
65 kN145 NmM12x30
Technical details — DK2-VT-S

DK2-VT-S

Dimension drawing — DK2-VT-S
A min
42 mm
A optimum
45 mm
A max
49 mm
B
41 mm
C
22 mm
D
30 mm
E
4 mm
Socket Head Srew DIN 912
M12x30
Pressing force of Jaws (max)
65 kN
Tightening torgue (max)
145 Nm
Weight
180 g
Hardness of Jaws
48-52 HRC
Dimensions
PDF drawings
STEP (3D)
STEP (3D)

DK2-VTI-S

65 kN145 Nm1/2-1 1/4
Technical details — DK2-VTI-S

DK2-VTI-S

Dimension drawing — DK2-VTI-S
A min
1,65 in
A optimum
1,77 in
A max
1,92 in
B
1,61 in
C
0,86 in
D
1,18 in
E
0,15 in
Socket Head Srew DIN 912
1/2-1 1/4
Pressing force of Jaws (max)
65 kN
Tightening torgue (max)
145 Nm
Weight
6,34 oz
Hardness of Jaws
48-52 HRC
Dimensions
PDF drawings
STEP (3D)
STEP (3D)
 FK2-VT-S 110 kN360 NmM16x40
Technical details — FK2-VT-S

FK2-VT-S

Dimension drawing — FK2-VT-S
A min
57 mm
A optimum
60 mm
A max
64 mm
B
56 mm
C
29 mm
D
42 mm
E
5 mm
Socket Head Srew DIN 912
M16x40
Pressing force of Jaws (max)
110 kN
Tightening torgue (max)
360 Nm
Weight
465 g
Hardness of Jaws
48-52 HRC
Dimensions
PDF drawings
STEP (3D)
STEP (3D)
