Raised Clamp Module D-Series
Description
Raised Clamp Module D-Series is designed for clamping tall workpieces. The module combines the RMRC-S31 riser with a D-series low-profile clamp, creating a raised clamping point above the base rail.
The module allows the workpiece to be clamped at a height of 29,4 mm from the rail surface.
Features:
-
Designed for clamping tall workpieces
-
Combines RMRC-S31 riser stopper with D-series low-profile clamp
-
Clamping height: 29,4 mm from rail surface
-
Compatible with OK-VISE Multi-Rail RM and RL system
-
Designed for use with RM high stopper or a second Raised Clamp Module
Details
| Set Code | Clamp type | Clamp model | Stopper model | Dimensions | Step file (3D) |
| RMC-DSSS3 | Smooth | DK2-VT-S | RMRC-S31 |  |
 |
| RMC-DSSR3 | Serrated | DK2-VT-SR | RMRC-S31 | |
|
Notes
-
Provides additional support when clamping large workpieces
-
Particularly useful in horizontal machining centers where stable support during loading and machining is required
