Locating Keys
Locating keys are intended for the precise locating of the rail on the T-slot base. By installing the locating key into the recess in the center of the bottom of the rail, the rail can be located perpendicular to the T-slots.
By installing them at the ends of the rails, the rail can be located in alignment with the T-slots. A bolt for installation ( DIN912M6X10) is included.
Details
| Code | Widht 1 | Widht 2 | Dimension | STEP (3D) |
| LK-1812 | 12 | 18 |  |
 |
| LK-1814 | 14 | 18 | |
|
| LK-1816 | 16 | 18 | |
|
| LK-18 | 18 | 18 | |
|
| LK-1820 | 20 | 18 | |
|
| LK-1822 | 22 | 18 | |
|
